| Specifications |
| Model |
CS-H90-R100-8H44WKFL |
| Camera |
| Image Sensor |
1/3″ Progressive Scan CMOS |
| Shutter Speed |
Self-adaptive shutter |
| Lens |
Top Lens: 2.8mm @ F1.6, Field of view : Diagonal 110°, Horizontal 96°, Vertical 54°
Bottom Lens: 6mm @ F1.6, Field of view : Diagonal 60°, Horizontal 52°, Vertical 28° |
| PT Angle |
Top Lens: Pan: 220°, Tilt: 10° (manual adjustment for vertical angle )
Bottom Lens: Pan: 324°, Tilt: 90° |
| Minimum Illumination |
0.5 Lux @(F1.6, AGC ON),
0 Lux with IR (*data is obtained from EZVIZ laboratories) |
| Lens Mount |
M12 |
| Day & Night |
IR-cut filter with auto switch |
| DNR |
3D DNR |
| WDR |
Digital WDR |
| IR Night Vision |
30 m (98 ft) |
| Color Night Vision |
Up to 40 m (131 ft) when two lenses point in the same direction |
| Video & Audio |
| Max Resolution |
2K+ (2560 × 1440) |
| Frame Rate |
Self-adaptive during network transmission |
| Video Compression |
H.265 / H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
Quad HD; Full HD; Standard adaptive bit rate |
| Audio Bit Rate |
Self-Adaptive |
| Network |
| Wi-Fi Standard |
IEEE802.11b, 802.11g, 802.11n |
| Frequency Range |
2.4 GHz ~ 2.4835 GHz |
| Channel Bandwidth |
Supports 20MHz |
| Security |
WPA-PSK/WPA2-PSK |
| Transmission Rate |
11b 11 Mbps, 11g 54 Mbps, 11n: 150 Mbps |
| Wi-Fi Pairing |
AP paring |
| Protocol |
EZVIZ cloud proprietary protocol |
| Interface Protocol |
EZVIZ cloud proprietary protocol |
| Wired Network |
RJ45 × 1 (10M / 100M Adaptive Ethernet Port) |
| Functions |
| Smart Alarm |
AI-powered human shape detection
AI-powered vehicle shape detection
Motion detection |
| Auto Tracking |
Supports |
| Customized Alert Area |
Supports |
| Two-way Talk |
Supports |
| Preset Locations |
Supports |
| General Function |
Anti-Flicker, Dual-Stream, Heart Beat, Password Protection, Watermark |
| Storage |
| Local Storage |
Supports microSD card (max. 512 GB) |
| Cloud Storage |
Supports EZVIZ CloudPlay storage (subscription required) |
| General |
| Operating Conditions |
-30°C to 50°C ( -22 °F to 122 °F )
Humidity 95% or less (non-condensing) |
| IP Grade |
Weatherproof Design |
| Power Supply |
IP65 + 2h rainstorm |
| Power Consumption |
MAX. 18W |
| Dimensions |
224 × 135 × 136 mm (8.82 × 5.31 × 5.35 inch) |
| Packaging Dimensions |
255 × 176 × 194 mm (10.04 × 6.93 × 7.64 inch) |
| Weight |
Net weight: 723 g (25.51 oz)
With Package: 1203 g (42.43 oz) |
| In the box |
| In the box |
– H90 Dual 2K+ Camera |
| – Power Adapter |
| – Drill Template |
| – Waterproof Kit |
| – Screw Kit |
| – Regulatory Information × 2 |
| – Quick Start Guide |
| Certifications |
| Certifications |
CE / UL / WEEE / RoHS / REACH |
